Comfort Circuit Diagrams adds another module for vehicle electronics to TecRMI, the information system for repair and maintenance information. In recent months information has been added on fuses and relays, part location, diagnosis measurement values, tyre pressure control systems and other electronic components. Now TecAlliance is completing its information offering in this area.
Starting in January 2015 TecRMI will include the new information module Comfort Circuit Diagrams in addition to the familiar circuit diagrams for engine management, air-conditioning system and Brake system.
The new module includes circuit diagrams for anti-theft systems, central locking system, seat heating, airbag systems, lighting, instrument clusters, electric window lifters, hi-fi, cruise control, immobiliser and other items. Even CAN bus systems and their networking are included. The Comfort Circuit Diagrams are available for all common European, Japanese and American vehicles from the model year 1992 on.
All circuit diagrams are displayed according to a standard; they are grouped clearly to ensure quick access to the information that is needed. Zoom and print functions also help the user. In addition to the circuit diagrams the corresponding component lists are available in the print view with complete component identification. Using the screen view is easy with the familiar mouse over functions.
At the TecAlliance exhibition stand at Automechanika in Frankfurt (Hall 5_6.1, Stand A01/A10) you can see how the new module works.
